| Technical specifications | |
|---|---|
| Input voltage | 12 Volt DC |
| Wattage | max. 36 Watt |
| Type | 2000 mm mains lead with LED plug-in connection 500 mm lead with LED socket |
| Dimensions | 140 x 6,5 x 5 mm |
| Remarks | installation on secondary side between transformer and ligtht, to be build into wood shelves (hole Ø 7 mm) or behind panels. for ON / OFF switching of connected LED lights, activation through wood or plastic, up to material thickness of approx. 30 mm, the electronic will adjust itself to the material thickness, not suitable for installation behind metal |
| Article code |
|---|
| 39.321.000 |
