| Technical specifications | |
|---|---|
| Input voltage | 12 - 24 Volt DC |
| Output voltage | 12 - 24 Volt DC |
| Wattage | max. 108 Watt at 12 Volt DC input max. 216 Watt at 24 Volt DC input |
| Frequency | 433.92 MHz |
| Type | 300 mm mains lead with LED plug- in connection, 4 - pin |
| Radio range | approx. 40 - 50 m in open area, reduced by obstructions e.g. metal or walls |
| Control | negative |
| Dimensions | 135 x 30 x 20 mm |
| Housing colour | white |
| Installation | with screws |
| Remarks | Radio receiver serves for the control of LED modules up to max. 216 W, with one or multiple radio remote controls, up to 10 radio receiver per radio remote control |
| IP Code | IP20 |
| Article code |
|---|
| 38.145.101 |
